D60 Fixture



SKU: 7410A1605 Categories: ,


The D60 fixture is the brightest variant in the Desire LED luminaire family. Sixty energy-saving LED emitters are combined onto each D60 fixture to provide powerful, high-intensity output. This round, PAR-shaped washlight is ideal for the stage, studio and anywhere brightness and color flexibility are required. Designed with the user experience in mind, the D60 luminaire features a user interface with Quick Setup options to simplify work. You can choose from Stage, High-Impact, XT (Exterior)/Architectural, General and Studio settings to customize the luminaire to your specific task. And you can further tailor the fixture to your needs by choosing profile and performance settings via the user interface. The D60 luminaire can be controlled from a DMX-enabled controller – like an ETC lighting control console – or run on its own by selecting the Stand Alone Mode on the unit.

• 60 LED emitters for maximum brightness
• powerCON/DMX in/thru
• Fan cooled
• Indoor use only

• Desire Lustr+ – x7 Color optimized with high-intensity white LEDs to create an ideal theatrical wash fixture. Full range color, with an emphasis on lighter colors and white – the stage lighting choice.
• Desire Vivid – the x7 Color System array is balanced for use as a high-intensity, high-saturation color-changing wash fixture.
• Studio HD – combines an equal number of warm white and cool white LEDs for variable color temperature mixing. Adds five additional x7 LED colors to fill the white LED spectral gaps. Provides the richest variable white light possible in an LED luminaire.
• Studio Daylight – contains 5600K LEDs for high-intensity, non-variable cool white output.
• Studio Tungsten – contains 3000K LEDs for high-intensity, non-variable warm white output.


Ships With: D60 luminaires ship with hanging yoke, and UL1573 powerCON cable with connector of choice.


Additional information

Weight 23.7 lbs
Dimensions 24 × 12 × 12 in
LED Array

Lustr+, Studio Daylight, Studio HD, Studio Tungsten, Vivid

Fixture Color

Black, Silver, White

Connector Leads

L520 Twistlock, Bare Ends, Edison, Stage Pin
