Description
This three-rung lighting ladder pairs with a 510-HD heavy duty pipe clamp rated to support up to 55 lbs., giving you a sturdier option than the 2-rung version for wider rigging spans. The added rung provides extra hang points across a single pipe or batten, making it easier to space out fixtures, drop boxes, cable looms, or other production gear without needing multiple clamps. Built for standard theatrical pipe grids, this lighting ladder is a common sight in theaters, schools, auditoriums, and live event venues, and holds up well to repeated load-in and load-out cycles.
Key Features Of 3 Rung Lightning Ladder
- Three-rung design – an extra rung over the 2-rung version gives this lighting ladder more spread for hanging multiple fixtures or a longer cable run across one pipe.
- Heavy duty pipe clamp included – the 510-HD clamp is rated to hold up to 55 lbs. and comes pre-attached, ready to mount straight out of the box.
- Standard theatrical rigging fit – sized for common batten and pipe grid diameters used in theatres, schools, and touring rigs.
- Compact for transport – folds down to 48 × 48 × 12 in. despite the added rung, so it still packs efficiently between shows.
- Durable steel build – 40 lbs. of solid construction designed to hold up under repeated load-in/load-out cycles.
How To Use The 3 Rung Lightning Ladder With 510-HD Heavy Duty Pipe Clamp
- Position the clamp on the pipe. Open the 510-HD heavy duty pipe clamp and set it around your batten or pipe where you want this lighting ladder hung.
- Tighten to secure. Close and fully tighten the clamp so the ladder sits flush and doesn’t slide or rotate once weight is added.
- Attach a safety cable. As with any rigging hardware, run a safety cable from the ladder to the pipe as a secondary fall-arrest measure — not included, so have one on hand if it’s not already in your inventory.
- Load your fixtures or gear. Distribute fixtures, drop boxes, or cable across all three rungs, keeping the total load under the clamp’s 55 lb. rating.
- Check before every use. Give the clamp and rungs a quick visual inspection each time for wear, bent rungs, or a loose clamp bolt before trusting this lighting ladder with a new load.
